Most appropriate for load control of bench scales, etc.

● Capacity 5/ 10/ 20/ 30/ 40 kg
● Constructed of Aluminum, Lightweight
● Most appropriate for load control of bench scales, etc.

Model	PW6C-5KG, PW6C-10KG, PW6C-20KG, PW6C-30KG, PW6C-40KG
Rated capacity	5 kg, 10 kg, 20 kg, 30 kg, 40 kg
Rated output	2.2±0.2 mV/V
Safe overload	150% R.C.
Maximum safe side overload	300% R.C.
Zero balance	0±0.12 mV/V
Non-linearity	0.0166% R.O. typ.
Hysteresis	0.0166% R.O. typ.
Compensated temperature range	-10 to +40℃
Safe temperature range	-10 to +50℃
Temperature effect on zero	0.0140% R.O./10℃(5/10/20 kg), 0.0093% R.O./10℃(30 kg), 0.0175% R.O./10℃(40 kg)
Temperature effect on span	0.0175% R.O./10℃(+20 to +40℃), 0.0117% R.O./10℃(−10 to +20℃)
Input resistance	300 to 500 Ω
Output resistance	300 to 500 Ω
Recommended excitation voltage	1 to 12 V
Insulation resistance	2000 MΩ or more
Degrees of protection	IP67
Cable	6 conductor shield cable 2 m Cable end: 7 wires
Cable color code	＋EXC：Blue ＋S：Green －S：Gray －EXC：Black ＋SIG：White －SIG：Red SHIELD：Yellow
Load cell material	Aluminum
Deflection at rated	0.5 mm or less
Natural frequency	5KG：225 Hz 10KG：331 Hz 20KG：473 Hz 30KG：573 Hz 40KG：606 Hz
Maximum off center distance	100 mm
Maximum platform size	300 × 300 mm
Weight	0.25 kg
